Meet Kraken: A New Golang Botnet in Development

Meet Kraken: A New Golang Botnet in Development

In late October 2021, ZeroFox Research discovered a previously unknown botnet called Kraken. Though still under active development, Kraken already features the ability to download and execute secondary payloads, run shell commands, and take screenshots of the victim’s system. It currently makes use of SmokeLoader—a piece of malware used to install other malicious software—to spread, quickly gaining hundreds of bots each time a new command and control server is deployed. Despite having the same name, it should not be confused with the Kraken botnet from 2008 as they have little else in common.

Standing Intelligence Requirements

For the most up to date list of ZeroFOX Threat Research’s Intelligence Requirements, please visit:

https://cloud.zerofox.com/alpha_team/advisories/14956

Recommendations

• Ensure antivirus and intrusion detection software is up to date with all patches and rule sets.
• Enable two-factor authentication for all organizational accounts to help mitigate phishing and credential stuffing attacks.
• Maintain regularly scheduled backup routines, including off-site storage and integrity checks.
• Avoid opening unsolicited attachments and never click suspicious links.
• Log and monitor all administrative actions as much as possible. Alert on any suspicious activity.
• Review network logs for potential signs of compromise and data egress.
• If not already enabled, turn on the compromised credentials rule for all relevant entities and ensure relevant emails are entered for those entities, or reach out to [email protected] for assistance.
• If one of your entities receives an alert, ZeroFox recommends immediate password changes for the affected account.

Details

Since October 2021, ZeroFox Research has been tracking Kraken – a previously unknown botnet targeting Windows that is currently under active development. Although the bot is basic in functionality, the author has been experimenting with new features while altering others. Current iterations of Kraken feature the ability to:

• Maintain persistence
• Collect information about the host for registration (varies per version)
• Download and execute files
• Run shell commands
• Steal various cryptocurrency wallets
• Take screenshots

“Open Source” Beginnings

While Kraken’s source code was likely not intended to be viewable by the public, the author originally uploaded the project to a fairly active GitHub profile on October 10, 2021. The project itself only had two commits, was extremely basic, and pre-dated any binaries ZeroFox observed in the wild. The source, however, was still similar enough to expedite some parts of our early analysis.

Figure 1. GitHub repository page for an early version of Kraken
Source: ZeroFox Research

Observed Infection Vector

Thanks to a tip by @abuse_ch, ZeroFox learned that Kraken originally spread in self-extracting RAR SFX files downloaded by SmokeLoader. These SFX files contained a UPX-packed version of Kraken, RedLine Stealer, and another binary used to delete Kraken. Current versions of Kraken are now downloaded by SmokeLoader directly. Kraken binaries are still UPX-packed but are now further protected by the Themida packer as well.

Figure 2. Screenshot of a Kraken SFX archive’s contents
Source: ZeroFox Research

Installation and Persistence

During Kraken’s installation phase, it attempts to move itself into %AppData%\Microsoft. The file name is hardcoded, though the author has changed it a few times. ZeroFox has observed file names such as taskhost.exe, Registry.exe, and Windows Defender GEO.exe.

To stay hidden, Kraken runs the following two commands:

1. powershell -Command Add-MpPreference -ExclusionPath %APPDATA%\Microsoft
2. attrib +S +H %APPDATA%\Microsoft<EXE_NAME>

The PowerShell command tells Microsoft Defender not to scan Kraken's installation directory, while the attrib command is used to hide the copied EXE file from an Explorer window that has not enabled the “Show hidden files, folders, and drives” option.

Kraken also makes use of the Windows Run registry key to ensure it starts every time the victim logs in.

Figure 3. Kraken’s Run key persistence
Source: ZeroFox Research

A mix of fake and real information is stored in a new registry key under HKEY_CURRENT_USER\Software; it is all currently unused after saving it during the installation. The name of the key is another hardcoded value, though it has also changed occasionally. Early versions of Kraken observed by ZeroFox created a key with the name “Networking Service” or some slight variation, such as “Networking5 Servic1e” and “Netrworking5r Servirc1er”.

Figure 4. Kraken registry information
Source: ZeroFox Research

Aside from the hard-coded name for the registry key, the following information shown in Figure 4 has remained the same in every version ZeroFox has encountered in the wild:

• ID - obfuscated UUID
• INSTALL - installation timestamp
• LAST - empty
• NAME - obfuscated binary and Run key name (minus file extension)
• REMASTER - always “nil”
• VERSION - always “0.5.6”

Features

Kraken’s feature set is fairly basic for a botnet. Although not present in earlier builds, the bot is capable of collecting information about the infected host and sending it back to the command and control (C2) server during registration. The information collected seems to vary from build to build, though ZeroFox has observed the following being collected:

• Hostname
• Username
• Build ID (TEST_BUILD_ + the timestamp of the first run)
• CPU details
• GPU details
• Operating system and version

The botnet also features the ability to download and execute files. Originally, Kraken contained separate but similar functions for downloading files for different situations, such as updating the bot itself, executing secondary payloads, and receiving files through direct socket connection.

These functions have since been combined into one, while the redundant functions were removed.

Kraken’s operators are able to run shell commands on infected hosts from the dashboard as well, returning the results back to the C2 server.

SSH brute-forcing functionality was added to some builds but was quickly removed. This function was hardcoded to attempt logging in as the root user of a given target and assumed a server would be listening on the default port. ZeroFox did not see any evidence of this feature being used, likely explaining its quick removal.

Immediately upon execution, Kraken takes a screenshot to send to the C2. A “ScreenShot” command also exists if the operator decides to take screenshots of the victim’s system on demand.

The most recent feature addition is the ability to steal various cryptocurrency wallets from the following locations:

• %AppData%\Zcash
• %AppData%\Armory
• %AppData%\bytecoin
• %AppData%\Electrum\wallets
• %AppData%\Ethereum\keystore
• %AppData%\Exodus\exodus.wallet
• %AppData%\Guarda\Local Storage\leveldb
• %AppData%\atomic\Local Storage\leveldb
• %AppData%\com.liberty.jaxx\IndexedDB\file__0.indexeddb.leveldb

Currently supported commands are:

• Position - Unknown
• ScreenShot - take a screenshot
• SHELL - run a Windows shell command with cmd
• UPLOAD - download and execute an EXE

Figure 5. Original regular expressions used to parse received commands
Source: ZeroFox Research

Dashboards

Multiple versions of the administration panel or dashboard have been created since October 2021. While the original code found on GitHub did include a server, it did not have a web-based interface for interacting with the botnet.

Kraken Panel

ZeroFox observed two versions of this panel. The first panel was fairly simple and required no authentication to view statistics. Uploading files or interacting with the botnet in any way, however, did require a “unique key” and a “team” value to be provided.

Figure 6. English-translated version of the first C2 panel
Source: ZeroFox Research

The second version of the Kraken Panel appeared near the end of November 2021. Although this version required authentication, the operator(s) did not stick with it for very long.

Figure 7. Login page for the second version of the Kraken Panel
Source: ZeroFox Research

Anubis Panel

The current version of the C2 has undergone a total redesign—complete with a new name, Anubis. The Anubis Panel does not currently require authentication and provides far more information to the operator(s) than the original Kraken Panel. In addition to the previously provided statistics, it is now possible to view command history and victim information.

Figure 8. Dashboard for the Anubis Panel
Source: ZeroFox Research

An update to the Anubis Panel added the ability for operators to be more selective when choosing targets for commands. In all versions up until recently, the operators had to choose the number of victims to target with the command. This latest update allows commands to be run on specifically-chosen targets by external IP address or geolocation.

Figure 9. Selecting a victim by external IP to run a shell command
Source: ZeroFox Research

The Anubis Panel also allows operators to view task or command history via the dashboard and TASK page. The page showed information such as the ID generated for the task, the command being sent, how many victims the command should be sent to, the targeted geolocation, and a timestamp of when the task was initiated.

Initially, every task investigated by ZeroFox resulted in a version of RedLine Stealer being downloaded and executed on the victim’s machine. Some shell commands were observed as well, though these were only used to download more RedLine payloads using curl.

Figure 10. TASK page showing command history
Source: ZeroFox Research

As the operators behind Kraken continued to expand and gather more victims, ZeroFox began observing other generic information stealers and cryptocurrency miners being deployed. As of this writing, the botnet appears to be collecting around USD 3,000 every month.

Figure 11. Mining statistics from the cryptocurrency mining pool Ethermine
Source: ZeroFox Research

Bonus

After the screenshot functionality was added, ZeroFox discovered a screenshot of what is likely the operator’s own desktop or development machine. Although the operator was not listed among the victims in the dashboard, a screenshot likely taken during a period of testing was still available. Several items of interest can be seen in Figure 12 below, including:

• A batch script used to build and UPX-pack the bot
• A partial view of the source code
• SQLite database files related to Kraken on the desktop
• Binaries matching file names of RedLine payloads ZeroFox received
• A directory that existed on one of the C2s – “Particles.js” directory
• Name of the botnet in the file path of the Explorer window
• Social media the operator may have been logged into (VK tab)
• Current file name of the bot when uploaded to the C2 – “build_dl”

Figure 12. Screenshot of the actor’s desktop
Source: ZeroFox Research

After moving the C2 to another server, the operator left a second screenshot available.

Figure 13. Second screenshot of the actor’s desktop
Source: ZeroFox Research

Conclusion

While in development, Kraken C2s seem to disappear often. ZeroFox has observed dwindling activity for a server on multiple occasions, only for another to appear a short time later using either a new port or a completely new IP. By using SmokeLoader to spread, Kraken quickly gains hundreds of new bots each time the operator changes the C2. Monitoring commands sent to Kraken victims from October 2021 through December 2021 revealed that the operator had focused entirely on pushing information stealers – specifically RedLine Stealer. It is currently unknown what the operator intends to do with the stolen credentials that have been collected or what the end goal is for creating this new botnet.

MITRE ATT&CK

IOCs

IP Addresses

• 65.21.105.85
• 91.206.14.151
• 95.181.152.184
• 185.112.83.22
• 185.112.83.96
• 185.206.212.165
• 213.226.71.125

SHA256 Hashes

• 1d772f707ce74473996c377477ad718bba495fe7cd022d5b802aaf32c853f115
• d742a33692a77f5caef5ea175957c98b56c2dc255144784ad3bade0a0d50d088
• ddf039c3d6395139fd7f31b0a796a444f385c582ca978779aae7314b19940812
• dcaaef3509bc75155789058d79f025f14166386cec833c2c154ca34cfea26c52
• 54d36e5dce2e546070dc0571c8b3e166d6df62296fa0609a325ace23b7105335
• 095c223b94656622c81cb9386aefa59e168756c3e200457e98c00b609e0bb170
• 0f0cabb24d8cc93e5aed340cfc492c4008509f1e84311d61721a4375260a0911
• 2ced68e4425d31cca494557c29a76dfc3081f594ff01549e41d2f8a08923ef61
• 3215decffc40b3257ebeb9b6e5c81c45e298a020f33ef90c9418c153c6071b36
• ef3e0845b289f1d3b5b234b0507c554dfdd23a5b77f36d433489129ea722c6bb
• 7c76ca5eb757df4362fabb8cff1deaa92ebc31a17786c89bde55bc53ada43864
• 48c2f53f1eeb669fadb3eec46f7f3d4572e819c7bb2d39f22d22713a30cc1846
• 43f46a66c821e143d77f9311b24314b5c5eeccfedbb3fbf1cd484c9e4f537a5d
• 8c4294e3154675cd926ab6b772dbbe0e7a49cae16f4a37d908e1ca6748251c43
