Threat Update: Emotet

|by Alpha Team

banner image

Threat Update: EmotetV5 Inoculation Script "EmoCrash"

During the week of 17 February 2020, security researchers from Binary Defense released an Emotet inoculation tool called "EmoCrash" to trust group communities. The purpose of this script is to protect Windows computers from being infected by EmotetV5. The script, released in Powershell, modifies the Windows registry by setting two keys that cause EmotetV5 to crash when the malware checks the presence of these keys. The researchers recommended to deploy this script through ".. a Group Policy Object to set this script as a logon script for all users. After it has been executed by each user, the logon script can be removed, and the registry keys will persist. For non-privileged users, setting the key in the HKLM hive will fail, but the rest of the script will still run and successfully create the key under HKCU for that user."

Recommendations

  • Consider the impact that the Emotet malware has within your threat model for your organization. The ATT&CK page for Emotet has great resources on the malware family
  • Emotet is generally used to deliver other malware, including Ryuk ransomware, so having a good disaster recovery plan for ransomware is recommended

Details

The following section is pulled directly from the Binary Defence report. The content of the report was marked TLP:GREEN.

Changes to Registry:

The PowerShell script creates a new key in HKEY_LOCAL_MACHINE (HKLM) and an identical key in HKEY_CURRENT_USER (HKCU) for each logical volume present on the computer. Both key names are the logical volume serial number.

On 64-bit Windows, the HKLM key is created under:

HKLM:\SOFTWARE\WOW6432Node\Microsoft\Windows\CurrentVersion\Explorer

On 32-bit Windows, the HKLM key is created under:

HKLM:\SOFTWARE\Microsoft\Windows\CurrentVersion\Explorer\

On both 32-bit and 64-bit Windows, the HKCU key is created under:

HKCU:\SOFTWARE\Microsoft\Windows\CurrentVersion\Explorer\

The most important of these keys in the one set in the HKCU hive, because that is what Emotet will check if it is run by a non-privileged user. Therefore, it is important to run this script under each user account on the computer to create the keys in each NTUSER.DAT registry hive.

Result:

If Emotet attempts to run on a protected computer, it checks the registry to determine if it has been installed before and retrieve the randomly chosen filename that it previously used. If the keys have been set using this script, Emotet will crash and generate events with IDs 1000 and 1001 (application crash) in the Application Event Log. If Emotet had already been installed on the computer, the path of the crashed application will be a directory named the same as the file inside it (the directory name does not have the file extension). The filename used is chosen randomly from the files in C:\Windows\System32 or C:\Windows\SysWOW64.

For example:

C:\Windows\SysWOW64\sqlsrv32\sqlsrv32.exe

C:\Users\Username\AppData\Local\wshrm\wshrm.exe

The directory is always a sub-directory of %APPDATA%\Local, or %SYSTEM% These application crash events can be used as a means of detecting failed Emotet run attempts.

#Emotet Inoculation Script
# **If run as Admin, will set keys under HKLM and HKCU. As user, will only set HKCU ** # Purpose: Emotet V5 Loader generates a value in # SOFTWARE\Microsoft\Windows\CurrentVersion\Explorer\
# that it uses as an infection marker, to store the path it was saved in.
# This key is named the Victim's Volume Serial ID, and the value contains the dropped # filename of Emotet V5's new filename generation algorithm.
# Emotet looks for this key at startup. If it doesn't exist, it creates it.  If it # does exist, Emotet reads that key into a buffer after decrypting it.
# Emotet does not check if the size of the value is larger than the buffer.
# This script overwrites that key with a new key that overflows the buffer, crashing # the malware.  It also generates event IDs 1000 and 1001 in the Application log.
# Authors: James Quinn, Binary Defense
# Grabs the VolumeSerialNumbers and sets a registry key in Explorer with # type=REG_BINARY and a value too large for Emotet to handle, overwriting the # destination buffer, which crashes Emotet.
#
function GenerateData{
[byte[]]$string
for ($i = 1;$i -lt 0x340;$i++){
   $hexNumber = $i % 10
   $string += [byte[]]$hexNumber
}
$string += [byte[]](0x51,0x75,0x69,0x6e,0x6e,0x75,0x6e,0x69,0x7a,0x65,0x64)
return $string
}
# 64-bit Windows
if (([IntPtr]::Size) -eq 8){
$Akey = "HKLM:\SOFTWARE\WOW6432Node\Microsoft\Windows\CurrentVersion\Explorer"
$key = "HKCU:\SOFTWARE\Microsoft\Windows\CurrentVersion\Explorer\"
}
else{ # 32-bit Windows
$Akey = "HKLM:\SOFTWARE\Microsoft\Windows\CurrentVersion\Explorer\"
$key = "HKCU:\SOFTWARE\Microsoft\Windows\CurrentVersion\Explorer\"
}
$volumeSerialNumbers = Get-WmiObject Win32_logicaldisk| Where-Object {$_.DriveType -eq 3} | select-object -ExpandProperty volumeserialnumber foreach ($x in $volumeSerialNumbers){
 # Remove any existing Emotet keys
Remove-ItemProperty -Path $AKey -Name $x  Remove-ItemProperty -Path $key -Name $x  $data = GenerateData  # Set keys and values  New-ItemProperty -Path $key -Name $x -Value ([byte[]]($data)) -PropertyType Binary  New-ItemProperty -Path $AKey -Name $x -Value ([byte[]]($data)) -PropertyType Binary
}

Tags: malware, global, financial services
